Switching AC DC Adapter For Led Lights , LED Tape Power Supply 15W Overload Protection

Product Categories

Changzhou LuxLED Lighting Technology Co.,Ltd

Contact Now

Switching AC DC Adapter For Led Lights , LED Tape Power Supply 15W Overload Protection

Brand Name : OEM

Model Number : LLD-SP8A

Certification : CE TUV EMC LVD RoHS

Place of Origin : Changzhou

MOQ : 200PCS

Price : Negotiable

Payment Terms : T/T Paypal

Supply Ability : 100000PCS

Delivery Time : 15-20 working days

Packaging Details : 100PCS per Carton

Item : Switching power supply for strip light

Model : LLD-ADPXA

Input : AC100-240V 50/60Hz

Output : 12VDC XA

Power : 180W

warranty : 3 years

Contact Now

12V 1A 5A 10A 15A 20A 30A LED Strip Power Adaptor Driver Power Supply for Strip Light

Features:

Universal AC input / full range

It's good quality & high performance

Input:AC110-220V 50/60Hz

Out put: DC 12V

DC12V:1A/2A/3A/5A/10A/15A/20A/30A

100% full load burn-in test

Protections: overload/ over voltage/ short circuit

Cooling by free air convection

This Power Supply Unit "DOES NOT come with installation instruction, wiring cable, on/off switch, or screws.

How to calculate Support max LED Strip Length:

Assumption: Your LED Strip 60LEDs/m, and each LED 0.2W, then calculate max LED Strip Length: 0.2W/LED × 60LEDs/m=12W/m, 60W(this listing)÷12W/m=5m, So, Support the LED Strip(60LEDs/m, 0.2W/LED) Length (Max)=5M

Connection:

L, N: AC power input

GND: DC power output "-"

V: DC power output "+"

+V / ADJ: Adjust the output voltage

Safety Compliance: CCC/ FCC / CE

Working Temperature: 0~40

Storage Temperature: -20~60

Ambient Humidity: 0~95% Non-Condensation

Products specification

Item	Output current	Output voltage	Input voltage	Power	Size	Weight
1	1.25A	DC12V	AC85-265V	15W	743cm	60g
2	2A	DC12V	AC85-265V	24W	963cm	110g
3	3A	DC12V	AC85-265V	36W	964cm	130g
4	5A	DC12V	AC85-265V	60W	1184cm	170g
5	10A	DC12V	AC85-265V	120W	13104cm	340g
6	15A	DC12V	AC85-265V	180W	20104cm	500g
7	20A	DC12V	AC85-265V	240W	20115cm	640g
8	30A	DC12V	AC85-265V	360W	22125cm	790g

IN-DOOR USE ONLY!
